EPIC Kraken Tire Inflation System GEN2 for 2018+ Jeep Wrangler & Gladiator (JL/JT)

Ginger Advice: Using the new ARB Brushless compressor requires you to do some detailed electrical work. Unlike the old Classic ARB compressor, the new Brushless compressor power harness includes a circuit board responsible for staggered starting and fault detection. If you are uncomfortable with performing precise electrical work, we highly suggest sticking with the much easier install of the old Classic ARB compressor. Check out our install guides/videos (attached below) before making your decision.

Now Onto The Product Details!

Release the Kraken! Don't be a chump and air-up your tires one at a time... air-up all four tires at once with our EPIC Kraken Air-Inflation System. The Kraken has been in the wild for 3+ years with 1,000s of happy end users. Please take a look at the videos and information provided to see why the Kraken is the premier air-up solution for your Jeep.

The EPIC MFG team has put together a form-fitting mounting system that elegantly tucks your ARB Twin Compressor under the front passenger-side seat in your Jeep - a space that is otherwise unused. With simple quick-connect fittings, air lines are easily plumbed inside of the vehicle to provide compressed air to both sides of the vehicle for easy and fast inflation of your four tires simultaneously. All GEN2 Kraken kits include a full set of our upgraded Deep Dive Slim Closed-Flow Air-Chucks!

Kit Contents:

1. Front Passenger-side Seat Compressor Mounting Bracket.
2. Front Driver-side Seat Air Bulkhead Mounting Bracket.
3. Compressor Air Intake Filter Protection Plate.
4. Two Pre-Assembled Dual Tire Hose Whips with Deep Dive Slim Air Chucks.
5. Pre-Assembled Plug & Play Power Switch Wiring Harness (ARB Classic variant only).
6. Loose Electrical Components which are required for you to modify the ARB power wiring harness (ARB Brushless variant only).

7. Tire Hose Storage Bag w/ Hose Divider, courtesy of our friends at Adventure Trail Gear.
8. Everything needed for a tidy installation: air lines, fittings, crimp terminals, electrical components and cross-over tubes - no trips to the hardware store necessary!
9. A nifty, high-quality 3M reflective Kraken decal to show your friends you know what's up.

Using only the very best hardware, the mounting plates/brackets are anodized aluminum, and laser-etched for style and durability. All air fittings and tubing are of superb quality. There simply is not a better 4-tire inflation system available for your Jeep. Ask your mom - she knows.

This is a no-drill installation and we've simplified the electrical preparation component of the installation as much as possible, with inclusion of Pre-Assembled Power Switch Wiring Harness (ARB Classic Compressor) or electrical components (ARB Brushless Compressor).

You will need to supply your own ARB #CKMTA12 Classic Twin Air Compressor or ARB #CLBTA12 Brushless Twin Air Compressor - SOLD SEPARATELY - both of which will come with the appropriate compressor power wiring harness, power rocker switch and assorted mounting hardware.

In our testing, Classic ARB Twin Compressor owners can expect to inflate four 37" tires simultaneously from 12PSI to 32PSI in about 7 minutes or less. Brushless ARB Twin Compressor owners can expect to do the same in about 4.5 minutes or less. Choosing to go with the Brushless ARB Twin Air Compressor will result in a 30% reduction in overall inflation time, thanks to its 50% increase in output over the Classic model - 6.2CFM vs 4.7CFM @ 29PSI.

Please Note:

• This kit works for all 2018 + Jeep Wrangler JL models (2 & 4 door) and 2020+ Jeep Gladiator JT models. All powertrain options are supported including: EcoDiesel, 3.6L V6, 2.0L Turbo, 4XE, Factory 392 and AMW4x4 V8 Engine Conversion Kits).
• This kit will not work in a Jeep Wrangler JK or any other vehicle.
• The kit is designed specifically for Genuine ARB (#CKMTA12) Classic Twin Air Compressor and ARB (#CKBLTA12) Brushless Twin Air Compressors. There are several ARB compressor knock-offs on the market which will may work out of the box with our kit. It may be possible to use comparable compressors, but that's up to you.
• Our included closed-flow air chuck fittings are intended for standard length wheel valve stems and may not work well with fast inflation/deflation valves or wheels with deeply recessed valve stem access. Alternative air chucks may be required to suit your unique application.

• Compatible with RHD export models - will require extending the air compressor power harness. Reach out for a custom shipping quote if you are located outside of North America.

Install Time: 2-3 hours

We strongly recommend watching the entirety of our latest Kraken System installation and system usage video for your chosen compressor variant linked below.

ARB #CKBLTA12 Brushless Twin Compressor Variant:

Installation Guide: Click for Installation Guide (Ver 1.1 - July 31st, 2025)

Installation Video: Click for Installation Video (GEN2 Kraken Brushless Twin Compressor)

ARB #CKMTA12 Classic Twin Compressor Variant:

Installation Guide: Click for Installation Guide (Ver 1.1 - July 31st, 2025)

Installation Video: Click for Installation Video (GEN1 Kraken Classic Twin Compressor)

If you have any questions about this product, please email us at info@epic-4wd.com

ARB Classic Twin Compressor (#CKMTA12) Install Video

ARB New Brushless Twin Compressor (#CKBLTA12) Install Video

Customs Classifications

• All Products Made in Canada.
• Fabricated Aluminum Air Compressor Mounting Bracket Kit for Portable or Stationary Use.
• Multi-Tire Air Hose Set for Passenger Vehicle Tire Inflation.
• Storage Bag for Multi-Tire Passenger Vehicle Inflation System Hoses.
